96W 24VDC Triac & 0-10V CV Driver MUP96AT-1W24V-B

Short Description:

· Single channel constant voltage output,4A Max

· Wide input voltage of 120VAC ~ 277VAC

· Dimming range of 0.1-100%, and dimming effect smooth, no flicker

· 100% output when no dimming signal input, can be used as normal power supply

· Protection: Over load; short circuit; Over Current

· IP20, suitable for indoor LED lighting application


Product Detail

Product Tags

96W 24VDC Triac & 0-10V CV Driver MUP96AT-1W24V-B

MUP96AT-1W24V-B is a constant voltage mode output LED driver. This driver can be controlled by external signal Phase-Cut ,0-10V to achieve a smooth dimming effect.

Technical Parameters

Model MUP96AT-1W24V-B
Input Efficiency ≥88%@230VAC, full load
Voltage 120VAC-277VAC
Frequency Range(Hz) 50/60Hz
AC Current(max) 0.6Amax@230VAC   1.1Amax @120VAC
PF ≥0.95@230VAC, full load
THD <10%@230VAC, full load
Inrush Current(max) Cold start,35A@230VAC590us
Standby power <2.5W@230VAC
No load power <2.5W@230VAC
Turn on delay Time <0.75s, at230Vac (When the light begins to shine)
Output Current 4A
Voltage 24VDC
Voltage Range 24VDC ±5%
Power 96W
Channel 1
Function Dimming Type 0-10V/TRIAC (120VAC)
Dimming Range 0.1%-100%(0-10V)
Dimming curve Logarithm (0-10V)
Flicker No Flicker
Protection Short Circuit Switch off the output power, working automaically after troubleshooting.
Over Load Voltage and current drop, self-recovery after troubleshooting
Over Current Voltage and current drop, self-recovery after troubleshooting
Safety&EMC Surge L-N 2500VAC L-N-PG 2500VAC3750Vac/1min/<5mA 1500Vac/1min/<5mA 500Vac/1min/<5mA
Withstand Voltage I/P-O/P: I/P-PG: O/P-PG:
Safety standards UL8750 UL1310 CSA25013.CSA Class P
EMC Eission FCC PART15B
EMC Immunity IEC 61000-4-2-3-4-5-6-8-11
Insulation Resisance 5MΩ
Others Working Temp. -20℃~+60℃ (-4°F~140°F)
Storage Temp., Humidity -40℃~85℃(-40°F-185°F), 20-90%RH
tc 85℃ (185°F)
Material Metal
IP Rating IP20
Lifetime 50,000h@ta:50℃(122°F)
Warranty Condition 5 years
Switch Cycle 25,000 times
Packing(weight) Net weight: 937g( 2.1 lb)±5%/PCS; 10PCS/Carton;9.6kg(21 lb)±5%/Carton; Carton Size: 254*254*192mm (10*10*7.55 Inch) (L*W*H)
Dimension 241*81*38mm (9.48*3.18*1.5 Inch) (L*W*H)
