200W 12VDC 1ch Waterproof Non-dimmable CV Driver OWP200-1W12V-T
Product Features
·Single-channel constant voltage output, per channel 16.7A Max
·Input Voltage Range 120-277Vac
·Protection: short circuit, Overload, Overcurrent, Overtemperature
•50,000Hour Life @ tc=90℃
•5 Year Warranty
•Flicker free
•Safety according to UL8750 &UL 1310
·Suitable for Dry , Damp & Wet Locations
Technical Paramaters
|
Model |
OWP200-1W12V-T | |
|
Input |
Efficiency | ≥87%@120VAC, full load |
| Voltage | 120VAC-277VAC | |
| Frequency Range(Hz) | 50/60Hz | |
| AC Current(max) | 2.4Amax @120VAC, 1.2Amax@230VAC, 1.0Amax@277VAC | |
| PF | ≥0.98@120VAC, ≥0.95@277VAC, full load | |
| THD | <10%@120VAC, <15%277VAC, full load | |
| Inrush Current(max) | Cold start, 25.75A@120VAC 348us; 52.5A@230VAC 340us; 67.5A@277VAC 344us, | |
| Standby power | <0.5W@120VAC | |
| No load power | <0.5W@120VAC | |
| Turn on Time | <0.50s, @120Vac (When the light begins to shine) | |
| Output | Current | 16.7A |
| Voltage | 12VDC | |
| Voltage Range | 12VDC±5% | |
| Power | 200W | |
| Channel | 1 | |
| Overpower limit | ≥120% | |
| Ripple Voltage | ≤200mV(p-p) | |
| Protection | Short Circuit | No output, Auto-recovery after Fault Clearance |
| Overload | No output, Auto-recovery after Fault Clearance | |
| Overcurrent | No output, Auto-recovery after Fault Clearance | |
| Overtemperature | Reduce power 50%, auto-restart after normal temperature | |
| Safety&EMC | Surge | L-N :6kV L-N-PG:6kV |
| Withstand Voltage | I/P-O/P: 3000Vac/1min/<5mA I/P-PG:1800Vac/1min/<5mA O/P-PG:500Vac/1min/<5mA | |
| Safety standards | UL8750,EN61347-1,EN61347-2-13 | |
| EMC Emission | EN55015,FCC PART15 ClassB | |
| Insulation Resisance | 5MΩ | |
|
Others |
Working Temp. | -40℃~+60 ℃(-40°F~158°F) |
| Storage Temp., Humidity | -40℃~90℃ (-40°F~194°F), 20-90%RH | |
| tc | 90℃(194°F) for safety & life | |
| Material | Metal | |
| IP Rating | IP67 | |
| Lifetime | 50,000h@tc:90℃ (194°F) | |
| Warranty Condition | 5 years | |
| Switch Cycle | 25,000 times | |
| Dimension | 251*67.5*35mm(9.88*2.66*1.38 Inch)(L*W*H) | |
| Packing(weight) | Net weight: 950g (2.09lb)±5%/PCS; 30PCS/Carton;29kg(63.9 lb)±5%/Carton; Carton Size: 392*202*204mm(15.4*7.95*8.03 Inch)(L*W*H) | |
