90W 12VDC Non-dimmable Waterproof CV Driver LWP90-1W12V-T
Product Features
·Single-channel constant voltage output,8A Max.
·Support Leading edge (Triac)and Trailing edge (ELV)Dimmer
·Dimming range from 40VAC to 120V AC
·Dimming effect smooth,no flicker
·High efficiency:up to 88%
·Over current protection;Short circuit protection；Over voltage
·Suitable for indoor LED lighting application
| Mod el | MUP96T-1W12V | |
|
Output |
Channel | 1 |
| Voltage | 12VDC | |
| Frequency | 1000Hz PWM | |
| Current | 8.0A | |
| Power | 96W | |
| Current Accuracy | ±3% | |
| R & N (Max) | <300mV Vp-p | |
|
Input |
Voltage | 120VAC-277VAC |
| Frequency | 50/60Hz | |
| Dimming Voltage Range | 40-120VAC | |
| Efficiency | ≥88%@120VAC, Full Load | |
| PF | ≥0.99@120VAC, Full Load | |
| THD(Full load) | <10%（at 120V,50Hz，Full Load） | |
| Current | 1.1Amax@120VAC | |
| Inrush current | Cold Start,70A@120VAC | |
| Standby power | <4W | |
| Protection | Over Voltage | Hiccup，recovers after fault condition is removed |
| Over load | Hiccup，recovers after fault condition is removed | |
| Short circuit | Hiccup，recovers after fault condition is removed | |
| Over temperature | Shut down and auto-restart after normal temperature | |
| Safety&EMC | Surge | L-N:2.5kV; |
| Withstand Voltage | I/P-O/P: 3000VAC/1min/5mA | |
| Safety standards | UL8750/UL1310/CSA25013.CSA Class P | |
| EMC Eission | EN50515,EN61000-3-2 Class C,IEC61000-3-3 | |
| EMC Immunity | FCC ClassB(120V)/Class A(277） | |
| Function | Dimming type | Triac/ELV DIM |
| Dimming range | 5%-100% | |
|
Others |
Dimension | 243*40*30mm(L*W*H) |
| G.W. | 700g | |
| IP rating | IP20 | |
| Working temp. | -20℃~55℃ | |
| tc | 90℃ | |
| Relative humidity | 20~90% RH | |
| Lifetime | 50,000h@tc:70℃ | |
| Material | Metal | |
| Switch cycle | >100,000 times | |
