96W 840-1920mA CC LED driver ARC-DI-96X2I1920-MUV-D1S-LS
Features
·Universal AC Input Voltage(120-347VAC)
·Metal sheet case
·One isolated 0-10V dimming interface
·Flicker free, excellent camera compatibility
·Dual Output, Class2, Class P
·Operating temperature: -20℃~+50℃
·Comply with IEEE1789, UL8750
·Programmable
Output current(1mA step) Dim to off
·Aux power, 12V/200mA
·ANSI C62.41 Category B 6kV
Model list
|
Model NO. |
Rated Input Voltage |
Max Output power |
Default Output Current |
Output Current Range |
Output Voltage Rated |
Aux Power |
|
ARC-DI-96X2I1920-MUV-D1S-LS |
120-347Vac |
96W+96W max. |
840mA*2 |
(840-1920mA)*2 |
35-50VDC |
12V |
Paramaters
|
INPUT |
Parameter |
Min |
Typ. |
Max |
Note |
| Input Voltage |
120Vac |
- |
347Vac |
- | |
| Input Voltage range |
108Vac |
- |
382Vac |
- | |
| Rated Frequency |
47Hz |
50/60Hz |
63Hz |
- | |
| Input current |
- |
- |
2A |
@120Vac full load | |
| Inrush current |
- |
- |
100A |
230Vac, cold start (25℃) | |
| Power Factor |
>0.95 |
- |
- |
@120Vac 100% load | |
|
>0.9 |
- |
- |
@347Vac 100% load | ||
| T.H.D. |
- |
<5% |
@120Vac 100% load | ||
|
- |
<20% |
@347Vac 100% load | |||
| Efficiency |
- |
86-88% |
- |
@120Vac Vout=50V, Iout=1920mA, steady state | |
|
- |
88-90% |
- |
@347Vac Vout=50V, Iout=1920mA, steady state | ||
| Turn On Delay Time |
- |
- |
0.75S |
Cold Start, 1500-2100mA |
|
Output |
Parameter |
Min |
Typ. |
Max |
Note |
|
| Programmable Output Current |
840mA |
- |
1920mA |
Per Channel | ||
| Output current tolerance |
- |
- |
5% |
1500-1920mA | ||
| Output Voltage |
35V |
- |
50V |
The derating begins when the input voltage is less than 108 ±10%Vac | ||
| Output Power |
- |
- |
192W |
Total Power, See “Operating window” | ||
| Line Regulation |
- |
- |
3% |
- | ||
| Load Regulation |
- |
- |
5% |
VOUT from MIN. to MAX. | ||
| Ripple Current |
- |
- |
10% |
Full Load, (Iomax-Iomin)/(Iomax+Iomin) | ||
| Output Current Overshoot |
- |
- |
10% |
Turning Power ON | ||
|
0~10V or Resistor Dimming |
Dimming Curve | Linear. please see “Dimming curve”. | ||||
| Source Current on 0~10V Dimming Pin |
- |
200uA |
- |
- | ||
| Light Off |
- |
0.7±0.1V |
- |
- | ||
| Dimming Voltage for Full Bright |
- |
8.5V |
- |
- | ||
| Dimming Range |
1% |
- |
100% |
|||
| External Resistor Value at Full Bright |
- |
40 |
- |
kΩ | ||
| Leakage Voltage |
- |
- |
20 |
Voltage between DIM- and Ground | ||
|
Programming |
The driver can be programmed through Programming Port.·Output current(1mA step)
·OTP point of driver, LED thermal protection |
|||||
|
Programming Port |
the driver can be easily connected to a digital control system, to set the driver(eg: output current , dimming level, and so on). | |||||
| Programming software | USBNode Tool | |||||
| Programming tool | TBD | |||||
| Operating voltage |
- |
5V |
- |
|||
| Auxiliary source | Output Power |
- |
- |
2.4W |
- |
|
| Output Voltage |
- |
12VDC |
- |
- |
||
| Voltage tolerance |
- |
- |
8% |
- |
||
