150W 24V 0-10V CV Driver OWP150A-1W24V
Summary
OWP150A-1W24V is a waterproof constant voltage output LED dimming driver.
Supports 0/1-10V active signals, adjustable resistors, PWM, achieving smooth dimming effect.
Product Features
·Single channel constant voltage output, output current is 6.25A max
·Dimming range 0.1% -100% dimming, smooth dimming without any step or flicker
·Built in PFC chip to improve energy efficiency and reduce pollution to the power grid
·Waterproof rating IP67, suitable for outdoor lighting
·Protection: Overload, overcurrent, short circuit protection
·Lifespan of 50000 hours, 5-year warranty
Technical Paramaters
| Model | OWP150A-1W24V | |
|
Input |
Efficiency | ≥88%@120VAC, ≥90%@277VAC, full load |
| Frequency | 50/60Hz | |
| Voltage | 120VAC-277VAC | |
| Power Factor | 0.95@120VAC, 0.95@277VAC, full load | |
| THD(full load) | 10%@120VAC, 10%@277VAC, full load | |
| Current | 1.74Amax@120VAC, 0.74A@277VAC | |
| Inrush Current | Cold start, 38A@120VAC 268us, 79A@277VAC 116us | |
| Standby Power | <0.5W | |
| No load power | <1W | |
| Turn on delay Time | 0.75s (@120VAC, When the light begins to shine) | |
|
Output |
Current | 6.25A |
| Voltage | 24VDC | |
| Voltage Accuracy | ±5% | |
| Power | 150W | |
| Channel | 1 | |
| Over power limit | ≥120% | |
| Ripple | ≤720mV | |
| Frequency | 20KHz PWM | |
| Protection | Short Circuit | Turn off output, self recover after troubleshooting |
| Over Current | Reduce current protection, restore normal operation after troubleshooting | |
| Over Load | Reduce current protection, restore normal operation after troubleshooting | |
|
Safety & EMC |
Surge | L-N: 6KV L-N-PG: 10KV |
| Withstand Voltage | I/P-O/P: 3750Vac/1min/<5mA, I/P-PG:1500Vac/1min/<5mA | |
| Safety standards | EN61347, GB19510 | |
| EMI Eission | EN55015, EN61000-3-2 GB17743 GB17625.2 | |
| Insulation Resisance | 5MΩ | |
| Function | Dimming Type | 0-10V |
| Dimming Range | 0.1%-100% | |
| Dimming curve | Logarithm | |
| Flicker | Flicker free | |
|
其它 |
IP Rating | IP67 |
| Working Temp. | -20~+50 ℃ | |
| Storage Temp., Humidity | -40~+85°C, 20~90% RH | |
| tc | 85℃ | |
| Lifetime | 50,000h@tc:85℃ | |
| Warranty Condition | 5years | |
| Switch Cycle | >25,000 times | |
| Material | Metal | |
| Dimension | 210*64*33mm(L*W*H) | |
| Packing(weight) | Net weight: 745g±5%/PCS; 20PCS/Carton; 15.4kg±5%/Carton; Carton Size:347*257*214mm(L*W*H) | |
